Important Note:

It should be realized that certain combinations of options are not achievable for all models. For example, it is not reasonable to expect to achieve high frequency response when combining replaceable tips with long fiberoptic cables and dark targets. Please consult with the factory when there are questions regarding such issues.

Options FOR SENSORS

You can link to descriptive details on many of these options by clicking on the option letter in the table below.

The standard PHILTEC sensor package provides a stainless steel sensor tip, a 3 foot long fiberoptic cable sheathed with PVC over steel monocoil, and DC-20 KHz bandwidth amplifier or DMS signal processing unit as one integral unit with the fiberoptic cable potted into the electronic enclosure. Many options are available whereby the sensor tip, fiberoptic cable and/or the sensor electronics can be customized. Several options can be combined into one unit and specified using the following format: Model D100-BC1LT for analog units or Model DMS-RC100-BC1LT for digital units.

Photo of Options
OPTION CODE FOR DMS FEATURE
A (Analog) No Temperature Stabilized Amplifier Minimizes Long Term Drift
A (Digital) Yes Provides two additional 12 bit analog outputs for muDMS sensors with USB output.
Photo of option B connector B Yes Replaceable Tip Configuration - In-Line Connector (not available for D6 or RC12)
2B Y Option 2B provides a 3 piece sensor system; amplifier, extension cable and probe.
Photo of Option B1B1 Y Replaceable Tip Configuration - Sensor Bulkhead Connector (not available for D6 or RC12)
Photo of Option Bv1Bv1 Y Connectorizes Sensor System With Single Channel Vacuum Passthru Hardware for 10 E-7 Torr (not available for D6, D12 or RC12)
Photo of Option Bv133Bv133 Y Connectorizes Sensor System With Single Channel Vacuum Passthru Hardware
Mounted in a 1.33" CF Flange, for 10 E-7 Torr (not available for D6, D12 or
RC12)
Photo of Option Bv2 Bv2 Y Single Channel Ultra-High Vacuum Passthru Flange for all D models (not available for D6 or D12).
Photo of Option Bv3Bv3 Y Single Channel Ultra-High Vacuum Passthru Flange for all RC models (not available for RC12).
Photo of Option BvFBvF Y Multichannel High Vacuum Passthru Assembly for 10 E-7 torr (not available for D6, D12, RC12).
C1 Y Interlocking Stainless Steel, temperature range of -270° to +340° C. Maximum strength & temperature range, good flexibility.
C2 Y Silicone Rubber only, temperature range of -62° to +232° C. Maximim flexibility, no crush resistance, no tensile strength.
C3 Y Silicone over PTFE Wrap, temperature range of -62° to +232° C. 2 meter max. length, light crush resistance, non-metallic
C4 Y Silicone over Steel Monocoil, temperature range of -62° to +232° C. Good flexibility, moderate crush resistance, moderate tensile strength.
C5 Y PTFE over SS Interlok, temperature range of -270° to +260° C. Provides vapor barrier protection, poor flexibility.
C6 Y PVC Shrinkwrap over Nylon Wrap, temperature range of +10° to +107° C. Good for long lengths, light crush resistance, non-metallic.
C7 Y Translucent PTFE, temperature range of -270° to +260° C. Does not outgas in vacuum, wide temperature range, poor flexibility, susceptible to ambient light interference.
C8 Y PVC Shrinkwrap only, temperature range of +10° to +107° C. Good flexibility, no crush resistance, long lengths OK.
C9 Y Annealed (semi-rigid) SS Tubing, temperature range of -270° to +340° C. Very poor flexibility, supports High Pressure.
C10 Y Silicone Over SS Interlok, temperature range of -62° to +232° C. Provides Electrical Isolation from SS Interlok.
C11 Polyolefin (Vapor Barrier) Shrink Tubing
D Y Reflectance Dependent Output
E Y Glass fibers having light beam spreads of 25, 30 and 66° are used to produce Philtec sensors. The narrower beams give longer operating ranges. Standard Cable Lengths are 3 feet. For lengths exceeding 3 ft., specify Option E and give total Cable Length, 49 Feet Maximum (15 m).

  • 25° fiber can be used with continuous lengths up to 10 feet.
  • 30° fiber can be used with continuous lengths up to 29 feet.
  • 66° fiber can be used with continuous lengths up to 49 feet.
Photo of Option Fv1Fv1 Y Low Vacuum Passthru for 10 E-4 Torr (1000 µPa). Provides Ø.375" x 3" L Solid Section on Fiberoptic Cable, Compression Fitting, and Stainless Steel Interlok Sheathing On Vacuum Side
Photo of Option Fv1Fv2 Y Low Vacuum Passthru for 10 E-4 Torr (1000 µPa). Provides Ø.250" x 3" L Solid Section on Fiberoptic Cable, Compression Fitting, and Stainless Steel Interlok Sheathing on Vacuum Side
Photo of Option Fv1Fv3 Y Low Vacuum Passthru for 10 E-4 Torr (1000 µPa). Provides Ø.500" X 3" L Solid Section on Fiberoptic Cable, Compression Fitting, and Stainless Steel Interlok Sheathing on Vacuum Side
G1 N Equips Sensor With An Additional Output, DC Coupled with 10x Gain and Adjustable DC Offset
G2 N Equips Sensor With An Additional Output, AC Coupled with 10x Gain
H1 N Provides D models with a high bandwidth amplifier, DC - 200 KHz
H2 N Provides D models with a high bandwidth amplifier above 200 KHz. Bandwidths up to 1.5 MHz (some models) can be specified.
H3 N Provides RC models with a high bandwidth amplifier, DC - 200 KHz. Bandwidths up to 350 KHz can be specified.
+Hn N Designating +H1 or +H2 or +H3 provides a sensor amplifier with two outputs: standard DC-20 KHz and a wideband output.
L N Equips sensors with a low bandwidth amplifier, DC-100Hz. Bandwidths as low as 10 Hz can be specified.
+L N Equips a sensor amplifier with two outputs: standard DC-20 KHz and a low frequency output, DC - 100 Hz
M N Digital Display - DC Volts
N N Low Noise Amplifier - The amplifier is optimized to operate with highly reflective targets only. This cuts noise floor in half, thereby doubling resolution (For RC sensors only)
O N Provides an adjustable 0 to -4 VDC offset control. This feature is used to eliminate the DC offset from the sensor output, thereby increasing readout resolution.
P N Polynomial Curve Fit For Operation In Non-Linear Ranges
Photo of Option QQ N Quick Disconnect AC Power Adaptor and BNC Output Connector
R Y Ambient Light Rejection - These devices operate with continuous light emission. Standard units are subject to ambient light pickup. In environments where background light is a problem, Ambient Light Rejection can be included by specifying Option R.
(Not available for models D6, D12).
Photo of Option SS Y Side-Viewing Sensor Tip
Photo of T1 Tip Option T1 Y Customized Sensor Tip, Straight
Photo of T4 Tip OptionT2 Y Custom Sensor Tip, Straight and Threaded, Standard Lengths
Photo of Option T3 T3 Y Custom Sensor Tip, Non-metallic, Peek or Torlon
Photo of T4 Tip Option T4 Y Simple Right Angle Tip
Photo of Option T5T5 Y Square Body Right Angle Tip, Unthreaded
Photo of Option T6T6 Y Square Body Right Angle Tip, Threaded
Photo of Option T7T7 Y Special Tip Made To Customer Specifications
T8 Y High Temperature Tip, 350°C Max.
T9 Y High Temperature Tip, 482°C Max.
T10 Y Custom Sensor Tip, Metallic, non-magnetic, Brass or Aluminum
T11 Y Custom Sensor Tip, Invar
V N Provides Sensor Amplifiers with 0 - 10 Volt Analog Output
Photo of Option WW Y Adds a sapphire window epoxied into the sensor tip. For high pressure or vacuum
Photo of Option WbWb Y Adds a sapphire window brazed to the sensor tip
Z N Additional Output with Linear Range Spanning 0 - 5 volts
